Multi-Function Wellsite
Storage Collector
Oil-gas collection. Separation. Self-heating. Metering. Pressure-driven tanker loading. Natural gas engine power. Everything a remote wellsite needs -- in one factory-built unit.
The Single Answer to the Remote Wellsite Production Problem
A remote oil well without pipeline infrastructure faces a specific set of operational challenges: how to separate and store the crude oil, how to heat it for tanker loading in cold weather, how to measure production from an individual well, how to load road tankers without a pump or electrical power, and how to monitor and manage the wellsite without a permanent operator. The multi-function wellsite storage collector addresses all of these with a single, factory-built, self-contained unit.
Off-Grid Single-Well Production
The single most common application. Hours from the nearest town, with no grid power or pipeline. The collector handles the full cycle autonomously: separating gas, heating oil, metering daily production, and loading oil into tankers. The natural gas engine powers the site instruments and lighting completely off-grid.
Small Multi-Well Cluster Production
For two to four closely-spaced wells. A single multi-function collector serves as the cluster gathering point. Individual well metering is achieved by routing one well at a time through the test/metering mode of the collector's separator section -- identical to a full gathering station but at a compact scale.
Early-Stage Field Development
During early stages when the permanent gathering station is still under construction, the collector provides the infrastructure needed to begin generating cash flow. When the permanent station is complete, this mobile asset can be disconnected and redeployed to a new location.
Extended Production Testing
Suitable for extended production tests where individual well performance must be accurately measured over weeks. The collector provides continuous metering, accumulates totals, and transmits data via the remote monitoring system to the engineering team base in real time.
Product Integration Capability
Incorporates LINSON OIL's separator technology, electric heating systems, elevated storage tanks, and metering packages into a single unit.
Seven Functions. One Unit.
How the Collector Works From Wellhead to Tanker.
Wellhead Production Collection
Accepts the full range of wellhead pressures and flow rates expected over the producing life of the well, from high-pressure new wells to mature declining wells.
Gas-Liquid Separation
Built-in two-phase or three-phase separator removes associated gas. Gas is routed to the engine for power, metered, or flared. Liquids proceed to heating.
Self-Heating (Wellhead Gas)
Integrated heating system fuelled by separated wellhead gas. Maintains crude oil above pour point throughout storage, ensuring it remains pumpable.
Metering (Oil, Gas, Water)
Continuous measurement. Data is stored locally, displayed on the HMI, and transmitted via GPRS/4G/Satellite to the base office.
Elevated Storage
30-50 m³ capacity tank mounted 2.5-4.5 m above ground. Provides static head for gravity/pressure loading and allows ground-level tanker positioning.
Pressure-Driven Loading
Uses wellhead pressure or gas blanket to push oil into the tanker without a pump. No pump maintenance, no failures, no electrical load needed for loading.
Remote Monitoring & Unmanned Operation
Transmits real-time production data, tank level, heating status, and alarms via GPRS/4G or satellite. Operates autonomously for 2-7 days between operator or tanker driver visits.
Engineering Specifications
| Parameter | Standard Range | Notes |
|---|---|---|
| Wellhead Inlet Pressure | 0.2 - 4.0 MPa (g) | Higher with pressure-reducing station upstream |
| Wellhead Inlet Temp | 20°C - 80°C | Cold climate: inlet heating available |
| Liquid Throughput | 5 - 200 m³/d (oil + water) | Per well production rate and storage cycle |
| Gas Throughput | 500 - 50,000 Nm³/d | Per GOR and liquid throughput |
| Separation Type | Two-phase or three-phase | Per water cut and disposal requirement |
| Storage Volume | 20 - 80 m³ | Standard: 40 m³; custom sizes available |
| Storage Elevation | 2.5 - 4.5 m (base above ground) | Per tanker loading head requirement |
| Heating System | Field gas-fired water bath heater | Electric heating available where gas insufficient |
| Metering -- Oil / Gas | Oval gear (±0.5%) / Vortex (±1.0%) | Coriolis and orifice options available |
| Tanker Loading | Pressure-driven (no pump) | Loading rate controlled by valve position |
| Power -- Controls | Natural gas engine (standard) | Solar + battery or Grid options available |
| Remote Monitoring | GPRS / 4G / Satellite | Real-time flow, level, temp, alarms |
| Design Codes | GB 150 / GB/T 20801 | ASME dual certification available for export |
Standard Unit & Customization Options
Included Standard Supply
- ▪ Gas-liquid separator vessel (two-phase)
- ▪ Field gas-fired water bath heater (integrated)
- ▪ Elevated storage tank (40 m³ standard; structural steel frame)
- ▪ Oil flow meter (oval gear) & Gas flow meter (vortex with temp/press compensation)
- ▪ Tank level gauge & level transmitter (4-20 mA)
- ▪ Natural gas engine power generation set (3-5 kW standard)
- ▪ Tanker loading connection (DN50 or DN80 flanged) & loading valve
- ▪ Local HMI panel: production totals, tank level, heating status, alarms
- ▪ Remote monitoring system: GPRS/4G data transmission
- ▪ All interconnecting piping, structural frame, and surface treatment
- ▪ Factory function test & comprehensive documentation package
OEM / ODM Options
| Three-phase separator | For high water cut & disposal |
| Coriolis oil flow meter | Higher accuracy & BS&W indication |
| Automated loading control | Totaliser stops loading at preset volume |
| Anti-theft loading valve | Lockable with tamper-evident seal |
| Solar + battery power | If gas volume is insufficient for engine |
| Satellite communication | Beyond mobile network coverage |
| Cold climate package | Insulation & heat tracing (-50°C rating) |
| Road-trailer mounted | Mobile unit for frequent redeployment |
| ASME Certification | For international export projects |
Factory-Tested Before Wellsite Deployment
Certified Equipment Throughout. Fully integrated in-house.
Sizing Verification
Verified against well data: GOR, liquid rate, water cut, pour point. Separator residence time and heater duty checked.
Vessel Fabrication & NDT
Fabricated per GB 150. CNAS-accredited NDT on pressure welds. Hydrostatic pressure tests conducted.
Instrument Calibration
Flow meters calibrated against traceable standards. Level transmitters and temp sensors checked.
Engine Integration Test
Engine started on test gas. Electrical output verified. Instrument loads confirmed operating from engine.
Integrated Function Test (FAT)
Flow introduced; level control, heating sequence, and remote data transmission all verified before dispatch.
Export Preparation
Prepared for transport, connections protected, calibration records packed. Delivery checklist issued.
Key Certifications
Autonomous Wellsite Production
Remote Wellsite Deployments
Supplied for remote single-well and small cluster-well applications across Shandong, Xinjiang, and other producing regions. Deployed as primary production infrastructure at new wells pre-pipeline, and as permanent units where pipeline export is uneconomic.
Integration of LINSON OIL Product Lines
This collector represents the most integrated product in our portfolio -- combining separator technology, heating equipment, elevated storage, and metering into a single unit. Because all components are manufactured in-house, there is no system integration risk.
Warranty & Support
Covers all fabricated vessels, piping, heating system, instruments, and controls. (Engine warranty coordinated via manufacturer).
Priority access to replacement instruments and communications modules.
After-Sales Support:
- Remote production data monitoring & troubleshooting
- Instrument recalibration service (on-site or bench)
- Re-engineering for significant well production changes
- Engineering support for unit redeployment
Well Production Data In.
Self-Contained Facility Out.
Sizing starts with your well production data. Send us your parameters, and our engineers will respond with a preliminary unit specification (separator type, heater duty, storage volume) within 1-2 business days.
Free Engineering Resource
- Preliminary unit configuration & sizing
- Tanker loading assessment (time per visit)
- Power & communication recommendations
* Reviewed by LINSON OIL process engineers.
